Ikeja Electric Network

networks

NB: Ckt = Circuit Kilometers

6 Business Units (BU)
10 Transmission Substations
84 33/11 kV Transformers
575 33/0.415 kV Transformers
6131 11/0.415 kV Transformers
1325MVA Installed Transmission Capacity
1260MVA Installed Transformer Capacity (33/11 kV)
251.4MVA Installed Transformer Capacity (33/0.415 kV)
1652.75MVA Installed Transformer Capacity (11/0.415 kV)
1620.64 Ckt Kms* Route Length 33KV Feeders
2087.5 Ckt Kms Route Length 11KV Feeders
9435.47 Ckt Kms Route Length of 415V Lines
22.0 Ckt Kms Longest Urban 33KV Feeder
15.7 Ckt Kms Average Route Length of Urban 33KV Feeder
